Appendix
Technical specifications
Technical specifications
Display
Resolution
9" unit 1280 x 720
12" unit 1280 x 800
16" unit 1920 x 1080
Type High Visibility SolarMax HD® IPS optically
bonded TFT
Brightness 1200 nits
Touch screen Full touch screen (multi-touch)
Viewing angles in degrees (typical value @
contrast ratio = 10)
80° top/bottom, 80° left/right
Electrical
Supply voltage 12/24 V DC (10 - 31.2 V DC min - max)
Power consumption - Max
9" unit 23 W +- 4 W
12" unit 30 W +- 5 W
16" unit 45 W +- 5 W
Recommended fuse rating
9" unit 5 A
12" unit 5 A
16" unit 5 A
Environmental
Operating temperature range -15°C to +55°C (5°F to 131°F)
Storage temperature -20°C to +60°C (4°F to 140°F)
Waterproof rating IPX 6 and 7
Humidity IEC 60945 Damp heat 66°C (150°F) at 95%
relative (48 hr)
Shock and vibration 100 000 cycles of 20 G
Position Built-in 10 Hz GNSS receiver for GPS and
GLONASS, supports combinations with
Galileo, Beidou, QZSS.
SBAS (WAAS, EGNOS, MSAS, GAGAN).
Interface/Connectivity
Ethernet
9" unit 1 port (5-pin connector)
12" and 16" units 2 ports (5-pin connector)
NMEA 2000 1 port (Micro-C)
NMEA 0183 1 talker/listener (4800, 9600, 19200, 38400
baud - via optional adaptor cable)
Sonar 2 ports
Video input 2 ports (Composite video RCA - via optional
adaptor cable)
6
Appendix | NSS evo3S Installation Manual
43
