Simrad NSS16 EVO3S - Dimensional Drawings

Dimensional drawings
9" unit
310.9 mm (12.24”)
287.0 mm (11.30”)
179.5 mm (7.07”)
166.3 mm (6.55”)
131.0 mm (5.15”)
(2.74”)
18.5 mm (0.73”)
69.6 mm
66.6 mm (2.62”)
296.2 mm (11.66”)
12" unit
377.1 mm (14.85”)
351.5 mm (13.84”)
240.6 mm (9.47”)
170.3 mm (6.70”)
78.1 mm
(3.07”)
225.3 mm (8.87”)
18.5 mm (0.73”)
349.0 mm (13.74”)
106.7 mm (4.
20”)
16" unit
462.1 mm (18.19”)
436.5 mm (17.19”)
263.9 mm (10.39”)
170.3 mm (6.70”)
79.6 mm
256.0 mm (10.08”)
434.0 mm (17.09”)
18.5 mm (0.73 ”)
(3.13”)
106.8 mm (4.21”)
