TripIntel
TripIntel lets you store and recall information on trips. You can use the information to make
informed decisions prior to commencing a trip, or when a trip is underway.
Ú
Note: Vessel Fuel setup is required for this feature. Refer to the unit's separate installation
manual.
Ú
Note: For best results, it is recommended to run software version 2.4.0 or newer in your
EP-85R Storage Device or latest software in your Fuel Data manager.
Select the TripIntel button on the Tool panel to display the TripIntel page.
Current trip statistics
The Information tab on the TripIntel page shows current trip statistics:
• Distance traveled
• Time traveled
• Average speed
• Maximum speed
• Fuel economy
• Fuel used
Automatic trip recording
There is an automatic trip detection feature. When you start navigating you are prompted to
start recording the trip if no trip is currently underway and your speed has been more than 2
knots for 20 seconds. You will be prompted to continue a trip or start a new trip if the trip
was not explicitly saved before a power off.
You can manually start the recording later from the TripIntel page.
You can turn off the automatic trip detection feature from the Tracks and Trip settings dialog.
7
46
TripIntel | NSS evo3 Operator Manual
