Selecting the work profile
The AP70/AP80 can be set up with 6 different work profiles associated with different work
modes or preferences. Use the AP70/AP80 controller to set up the different work profiles. In
the MFD, the active work profile is displayed in the Mode button of the MFD Autopilot
controller pop-up and the Mode selection pop-up. If the MFD has control of the autopilot,
you can use it to select which work profile is active.
To change the work profile using the MFD, the autopilot must be in standby mode.
1. Select the Mode button in the Autopilot controller pop-up to display the Mode selection
pop-up
2. Select the Work profiles button to display defined work profiles in the Work profiles
selection pop-up
3. Select the work profile you want to activate
4. Select Close to close the Work profiles selection pop-up.
Enabling and disabling thrusters
Select the Cmd/Thrusters button in the Modes selection pop-up to open the Cmd/Thrusters
selection pop-up.
The Cmd/Thrusters selection pop-up provides options to enable or disable thrusters.
Autopilot settings
The autopilot settings can be split between settings done by the user, and settings done
during installation and commissioning of the autopilot system.
• User settings can be changed for various operational conditions or user preferences
• Installation settings are defined during commissioning of the autopilot system. No
changes should later be done to these settings
Both user settings and installation settings depends on which autopilot computer that is
connected to the system.
60
Autopilot | NSS evo3 Operator Manual
