Sinclair QL Service Manual

As Issue 5R40 R41 4K7 5%, 1/4W
R42 R43 4K7 5%, 1/4W
R44 R45 4K7 5%, 1/4W
R100 R101 2K2 5%, 1/4W
DIODES
D12 D13 1N4148
As Issue 5D14 D15 1N4148
D22 D23 1N4148 (2)
INTEGRATED CIRCUITS
IC29 IC30 2G007-Issue 3
As Issue 5
ULA Ferranti
IC31 IC32 78M05 +5V Regulator
MISCELLANEOUS
HBC1 HBC2 A10021 As Issue 5 2-off each 7-way flex. connector/cable
TABLE 5.5 FINAL BOARD ASSEMBLY
Circuit Ref ISSUE 5 ISSUE 6 Notes Rating/% Tol Manufacturer/Type
CAPACITORS
C1 32 pF
As Issue 5
5% Ceramic
C2 22 pF 5% Ceramic/TB
C4 4.7 pF 25V, -10%+50% Electrolytic/Axial
C19 47 nF 50V
C20 47 nF 50V
C21 22 µF 16V Electrolytic/Radial
C22 22 pF 16V Electrolytic/Radial
C23 22 pF 16V, -10%+50% Electrolytic/Axial
C24 22 pF 16V, -10%+50% Electrolytic/Axial
C25 22 µF 16V, -10%+50% Electrolytic/Axial
C26 0.01 pF 20% Ceramic/TB
C27 0.1 pF 50V, -20%+80%
C28 0.1 µF 50V, -20%+80%
C29 220 pF 10%
C30 220 pF 10%
C31 16 pF 22 pF 5% Ceramic
C32 0.01 µF
As Issue 5
20% Ceramic/TB
C33 0.1 µF 50V, -20%+80%
C34 47 pF 5% Ceramic/TB
C35 100 µF -10%, +80% Electrolytic/Axial
C36 47 nF 50V
C37 470 pF 25V, -10%+50% Electrolytic/Axial
C38 4.7 µF 16V Electrolytic/Radial
C39 470 µF 25V Electrolytic/Radial
C40 4.7 pF 16V Electrolytic/Radial
C41 0.33 pF 50V Electrolytic/Radial
C42 47 pF 10V Electrolytic/Radial
C43 0.1 µF 50V, -20%+80%
C44 0.1 µF 50V, -20%+80%
C45 1 nF 2% Ceramic
C46 0.1 µF 50V, -20%+80%
C47 22 µF 16V Electrolytic/Radial
C48 0.01 µF 20% Ceramic/TB
C53 NOT USED 22 pF 5% Ceramic
DC1-29 0.1 pF 0.1 µF 50V, -20%+80%
RESISTORS
R1-R6 3K3 5%, 1/4W
R7 330R 5%, 1/4W
