Sinclair QL Service Manual

R8 47K
As Issue 5
5%, 1/4W
R9 3K3 5%, 1/4W
R10 680R 5%, 1/4W
R11 1K 5%, 1/4W
R12 3K9 5%, 1/4W
R13 10K 5%, 1/4W
R14 47R 5%, 1/4W
R15 330R 5%, 1/4W
R16 330R 5%, 1/4W
R17-24 10K 5%, 1/4W
R25 180R 5%, 1/4W
R26 3K3 5%, 1/4W
R27 3K3 5%, 1/4W
R28 1K 5%, 1/4W
R29 1K 5%, 1/4W
R32 820R 5%, 1/4W
R33 820R 5%, 1/4W
R46 1K 5%, 1/4W
R47 2K2 5%, 1/4W
R48 8K2 5%, 1/4W
R49 8K2 5%, 1/4W
R50 8K2 5%, 1/4W
R51 1K 5%, 1/4W
R52 1K 5%, 1/4W
R53 1K 5%, 1/4W
R54 47K (1) 1%, 1/4W
R55 2K2 1%, 1/4W
R56 6K8 5%, 1/4W
R57 11K 5%, 1/4W
R58 55K6 5%, 1/4W
R59 22K 5%, 1/4W
R61 15R 5%, 1/4W
R62-69 3K3 5%, 1/4W
R70 1M 5%, 1/4W
R71 2K2 5%, 1/4W
R72-79 33R 5%, 1/4W
R80 15M 0.5W
R35 100R 5%, 1/4W
R86 270R 5%, 1/4W
R87 1K 5%, 1/4W
R88 75R 5%, 1/4W
R89 1K 5%, 1/4W
R90 1K 5%, 1/4W
R91 47K 5%, 1/4W
R92 390R (2) 5%, 1/4W
R93 3K3 5%, 1/4W
R94 3K3 5%, 1/4W
R95 1K 5%, 1/4W
R96 2K2 5%, 1/4W
R97 1K 5%, 1/4W
R98 4K7 5%, 1/4W
R99 2K2 5%, 1/4W
R102 33K ZERO Ω (2) 5%, 1/4W
R103 33K ZERO Ω (2) 5%, 1/4W
R104 82R 82R (2) 5%, 1/4W

Sinclair QL Specifications

General

Processor	Motorola 68008
Clock Speed	7.5 MHz
RAM	128 KB (expandable to 640 KB)
ROM	48 KB
Operating System	Sinclair QDOS
Release Year	1984
Storage	Microdrive tape loop
Graphics	256x256 pixels, 8 colors
Ports	RS-232, ROM cartridge
Sound	Beeper (internal speaker)
