© Jul. 2022 1-2 AB10ERJN Operation Manual
PERFORMANCE PARAMETERS
Table 1-1 AB10ERJN specifications (continued)
ITEM
AB10ERJN (Metric) AB330ERJN (Imperial)
Drive motor (rated power/rpm) 3 kW, 1572 rpm
Hydraulic tank capacity 20 L 4.4 gal (UK)/5.3 gal (US)
Oil capacity of hydraulic tank 16 L 4.2 gal (UK)/3.5 gal (US)
Hydraulic system pressure 21 MPa 3046 Psi
Battery (number×voltage, capacity) 8×6V, 330Ah (lead-acid)
System voltage 48 VDC
Control voltage
12 VDC
GROUND BEARING DATA
Max tire load
3580 kg
7893 lb
Pressure against ground
725 KPa 105 Psi
ENVIRONMENT REQUIREMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280 ft
Allowable ambient temperature (-
lead acid battery)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium battery)
-20℃～40℃ -4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gases, inflammables and explosives.
WEIGHT
Gross weight (unladen) 6550 kg
14440 lb
Note:
a) The platform height plus the operator height (taken as 2m [6ft 7in]) is the working height.
b) The ground bearing data is approximate, without factoring different configurations, and should only be used in
adequately safe conditions.
c) In different areas, hydraulic oil, engine oil, coolant, fuel and lubricant should be added in accordance with the
environmental temperature.
d) In cold climates, auxiliary devices are needed to start the machine.
e) The loads of persons, accessories, tools and materials are factored into the rated platform capacity.
