Sinoboom AB10ERJN - Operation from Platform

© Jul. 2022 7-6 AB10ERJN Operation Manual
OPERATING THE MACHINE
FALL HAZARD
The platform leveling switch can
only be used for slight leveling of the
platform. Improper use may cause
the load/occupant to shift or fall.
6. Turn on the enable switch and meanwhile push
upward/pull downward the platform rotation switch
to rotate the platform anticlockwise or clockwise.
7. Turn on the enable switch and meanwhile push
upward/pull downward the jib up/down switch to
raise or lower the jib boom.
8. Turn on the enable switch and meanwhile push the
jib rotation switch to the left/right to rotate the jib
boom clockwise or anticlockwise.
To drive:
The drive function cannot be enabled from the ground
controller.
To steer:
The steer function cannot be enabled from the ground
controller.
OPERATION FROM
PLATFORM
UNSAFE OPERATION HAZARD
• Unless in emergency situations,
do not operate the machine from
the ground controller when there
is any person on the platform.
• Do not operate the machine if any
control handle or switch that
controls the movement of the
platform does not return to OFF
position after being released.
COLLISION HAZARD
When operating the boom, ensure the
area around or under the platform is free
of persons or obstacles.
Before operation:
1. Ensure the storage battery is well connected before
operating the machine.
2. Turn the ground/platform select switch on the
ground controller to platform control position.
3. Pull out the red emergency stop buttons on both the
ground and platform controllers to ON position.
To position the platform:
1. Depress the foot switch and meanwhile push
forward/pull back the main boom luffing switch to
raise or lower the main boom.
2. Depress the foot switch and meanwhile push the
main boom telescoping switch to the left/right to
extend or retract the main boom.
3. Depress the foot switch and meanwhile push
upward/pull downward the articulating boom luffing
switch to raise/lower the articulating boom.
4. Depress the foot switch and meanwhile push the
turntable rotation switch to the left/right to rotate the
turntable clockwise or anticlockwise.
5. Depress the foot switch and meanwhile push
upward/pull downward the platform leveling switch
to level up/down the platform.
FALL HAZARD
The platform leveling switch can
only be used for slight leveling of the
platform. Improper use may cause
the load/occupant to shift or fall.
6. Depress the foot switch and meanwhile push the
platform rotation switch to the left/right to rotate the
platform clockwise or anticlockwise.
7. Depress the foot switch and meanwhile push
upward/pull downward the jib boom up/down switch
to raise or lower the jib boom.
8. Depress the foot switch and meanwhile push the jib
boom rotation switch to the left/right to rotate the jib
boom clockwise or anticlockwise.
To drive:
1. Depress the foot switch and meanwhile push
forward/pull backward the drive/steer proportional
control handle to drive the machine forward or
backward.
2. Speed up: slowly push the handle off center.
3. Speed down: slowly push the handle toward center.
4. Stop: return the handle to center or release the foot
switch.
When the boom is in operating position, the drive speed
of the machine will be restricted.
