© Jul. 2022 2-2 AB10ERJN Operation Manual
MACHINE COMPONENTS
Table 2-1
1. Work platform 12. Upper articulating boom 23. Lower articulating boom
2. Foot switch 13. Counterweight 24. Lower connecting rod
3. Platform controller 14. Ground controller 25. Articulating boom luffing cylinder
4. Jib boom 15. Steering cylinder 26. Lower linkage
5. Jib boom cylinder 16. Front wheel 27. Drive motor
6. Upper leveling cylinder 17. Steering link 28. Motor controller assembly
7. Telescoping boom 18. Reducer and motor 29. Slewing mechanism
8. Main boom 19. Rear wheel 30. Storage battery
9. Main boom luffing cylinder 20. Chassis 31. Battery box
10. Upper connecting rod 21. Turntable cover (LH) 32. Emergency power unit
11. Upper linkage 22. Turntable cover (RH) 33. Power unit
Machine positions
Stowed position:
The main boom is fully lowered and retracted, and
the articulating boom is fully lowered.
Operating/raised position:
Any of the down limit travel switch of main boom, the
retraction limit travel switch of main boom or the
down limit travel switch of articulating boom does not
detect the limit signal.
