PRE-OPERATION FUNCTION TEST
AB10ERJN Operation Manual 6-13 © Jul. 2022
Table 6-5
Mode Test results
KG mode
When the load on the platform does not exceed 230kg (507 lb), the platform can be lifted to the
highest position.
When the load on the platform exceeds 230kg (507 lb), the buzzer will sound, the overload
indicator light will flash, the display screen will indicate overload, and all functions will be
inoperative. After the overloaded object is removed, all functions will be resumed.
Non-KG mode
When the load on the platform does not exceed 230kg (507 lb), the platform can be lifted to the
highest position.
When the load on the platform exceeds 230kg (507 lb), the buzzer will sound, the overload
indicator light will flash, the display screen will indicate overload, and certain functions will be
inoperative. But the telescoping boom will be allowed to retract. After the telescoping boom is
fully retracted, the main boom and articulating boom can be lowered. The turntable can be
slowly rotated. After the overloaded object is removed, all functions will be resumed.
