© Oct 2020 6-20 AB18EJ&18HJ Maintenance Manual
REPAIR PROCEDURES
Fault
Code
Description
Cause Check
58
Front right steer
sensor fault
Front right steer sensor fault Check the wiring of front right steer sensor
59 Clutch fault Clutch fault
Check whether the clutch can be properly
enagaged or the sensor correctly wired.
60 Low fuel level fault Low fuel level fault
Check whether the fuel level is too low or the
sensor correctly wired.
Table 6-8 General fault code description for electric motor controller
Fault
code
Description
Cause Check
0012
Overcurrent of pump motor
1. Encoder fault or circuit
interference;
2. There is a short to
Motor UVW;
3. Mismatch of motor
parameters;
4. Controller fault
1. Check the encoder surface for stains,
replace if necessary;
2. Check whether the 3–phase of motor
UVW is shorted or damaged, check the
controller UVW 3–phase for damage using
a multimeter;
3. Monitor the controller current when fully
loaded, re-match the motor if necessary;
4. If the above checks fail, replace the
controller.
0112
Overcurrent of FL motor
controller
0212
Overcurrent of FR motor
controller
0312
Overcurrent of RL motor
controller
0412
Overcurrent of RR motor
controller
0013
Current sensor fault of
pump motor controller
1. Motor UVW short-
circuited;
2. Current sensor of the
controller faulted
1. Check the 3–phase cable of UVW for short
circuit or current leakage;
2. If the above check fails, replace the
controller.
0113
Current sensor fault of FL
motor controller
0213
Current sensor fault of FR
motor controller
0313
Current sensor fault of RL
motor controller
0413
Current sensor fault of RR
motor controller
0014
Pre-charging fault of pump
motor controller
1. The voltage reduces
due to loaded B+
circuit;
2. Controller damage.
1. Check whether the controller B+ circuit is
linked to high-power load;
2. Check the KSI wiring, and measure the
voltage using a multimeter to check if it is
normal;
3. If the above checks fail, replace the
controller.
0114
Pre-charging fault of FL
motor controller
0214
Pre-charging fault of FR
motor controller
0314
Pre-charging fault of RL
motor controller
0414
Pre-charging fault of RR
motor controller
0015
Low temperature of pump
motor controller
The controller operates at
ambient temperatures
below –40 ℃.
1. 1. Raise the ambient temperature above–
40 ℃, restart the key switch and interlock
switch;
2. If the above checks fail, replace the
controller.
0115
Low temperature of FL
motor controller
