MACHINE COMPONENTS
GTJZ0612E&0812E&1012E&1212E Operation Manual 2-3 © Mar. 2022
Component
China CE CSA ANSI AS
Japan
Korea Poland
32. Left turntable cover
√
33. Ladder
√
Machine positions
Stowed position:
The machine comes in stowed position when fully retracted.
Non-operating position:
The machine remains in non-operating position when the down limit switch does not disengage.
Operating/raised position:
The machine comes in operating/raised position when the platform is raised until the down limit switch
disengages.
Note: The platform heights are as follows (from ground to platform floor) when the down limit switch disengages:
• GTJZ0612E: 2±0.3m (6ft 7in±12in)
• GTJZ0812E: 2.3±0.3m (7ft 7in±12in)
• GTJZ1012E: 2.8±0.3m (9ft 2in±12in)
• GTJZ1212E: 2.8±0.3m (9ft 2in±12in)
