GTJZ0612E&0812E&1012E&1212E Operation Manual 1-1 © Mar. 2022
1 PERFORMANCE PARAMETERS
Table 1-1 GTJZ0612E Specifications
MEASURE
0612E (METRIC) 2146E (IMPERIAL)
DIMENSION PARAMETERS
Max. platform height
6.3m 20ft 8in
Max. working height
8.3m 27ft 3in
Max. horizontal extension 0.9m 3ft
Length
2.45m 8ft
Width 1.17m 3ft 10in
Height (stowed, rails folded)
1.6m 5ft 3in
Height (stowed, rails up)
2.22m 7ft 3in
Wheel base 1.88m 6ft 2in
Wheel span
1.025m 3.4ft
Ground clearance (pothole guards
retracted)
0.1m
4in
Ground clearance (pothole guards
deployed)
0.025 m 0.98in
Tire size (diameter × width / type)
Φ380×125mm/Solid Φ15×5in/solid
Platform dimension (Length × Width ×
Height)
2.3m×1.15m×1.1m 7ft 6.5in×3ft 9in×3ft 7in
PERFORMANCE PARAMETERS
Rated load capacity of platform 550kg
1213 lb
Max. load capability of extended platform 120kg
265 lb
Max. platform occupancy (indoor/outdoor) 2 persons
Drive speed (stowed)
0~4 km/h
0～2.5 mph
Drive speed (raised)
0～0.8 km/h
0～0.5 mph
Uptime (in a no-load state)
33～38 s
Downtime (in a no-load state)
30～35 s
Gradeability
25%
Max. allowable inclination (front to back/left
to right)
3°/1.5°
Turning radius (inside)
0m 0ft
Turning radius (outside)
2.35m 7ft 8.5in
