OPERATING THE MACHINE
GTJZ0612E&0812E&1012E&1212E Operation Manual 7-5 © Mar. 2022
1. Keep a safe distance between the operator, ma-
chine and fixed platform.
2. Pay attention to the traveling direction of the ma-
chine when using the controller.
EXTENDING/RETRACTING
THE PLATFORM
UNSAFE OPERATION HAZARD
• While the platform is extending,
do not stand on the platform
extension. The platform extension
can be secured on three slots, do
not operate on the platform
extension that has not been
secured.
1. Press down the pedal, grasp the rail of extension
platform and push to extend the platform.
2. Press down the pedal, grasp the rail of extension
platform and pull to retract the platform.
3. Release the pedal, insert the extension platform
end into the slot to secure the extension platform.
FOLDING/UNFOLDING THE
RAILS
UNSAFE OPERATION HAZARD
• Do not fold the rails while the
machine is working.
• Fold/unfold the rails only when
the machine is stowed and
extension platform fully retracted.
CRUSH HAZARD
• Do not allow hands or arms to get
close to any place that may have
crush hazards.
The platform rails can be foldable for convenient
transportation. The rail folding system consists of the
fold-down rails of the extension platform and the fold-
down rails of the fixed platform.
To fold the rails：
1. Remove the platform control box and support.
2. Remove the both wire rope safety pins at the front
end of the extension platform. Fold the front end rail
of extension platform. Do not reach your hands into
the place that may have pinch hazards.
3. Fold down the rails on both sides. Do not reach
your hands into the place that may have pinch
hazards.
4. Remove the both wire rope safety pins at the rear
end of the fixed platform.
5. Carefully open the door and stand on the ladder or
ground.
6. Fold down the door and the side rails at the entry
door as a piece. Do not reach your hands into the
place that may have pinch hazards.
7. Fold the side rails. Do not reach your hands into the
place that may have pinch hazards.
To unfold the rails：
Operate in reverse order as stated above to unfold the
rails. Ensure the wire rope safety pins are properly
secured after unfolding the rails.
DRIVING ON A SLOPE
Before driving on a slope:
1. Determine the climbing ability of the machine.
GTJZ0612E: 25% (14°）
GTJZ0812E: 25% (14°）
GTJZ1012E: 25% (14°）
GTJZ1212E: 25% (14°）
2. Ensure the platform is fully folded.
3. Ensure that the slope where you plan to drive is less
than the angle of the machine’s climbing ability.
NOTICE
Climbing ability refers to the maximum permissible
percentage of the slope when the machine is on solid
ground with sufficient traction and the platform is car-
rying only one person. As the weight of the machine’s
platform increases, the machine’s climbing capacity
reduces.
