OPERATING THE MACHINE
To steer：
Move downwards the drive/steer enable switch and
hold the enable switch on the joystick and press the
steer left/right button to steer the machine left/right.
To select drive speed：
TIPPING HAZARD
The machine must be driven at low
speed when tilted.
When the machine tilt alarm sounds,
do not operation any function except
lowering, and not until the tilting
factor is eliminated can the machine
be used again.
1. With machine stowed, the machine can be driven in
high/low speed mode.
2. Move the drive high/low speed select switch to
select the desired drive speed. Move upwards the
drive high/low speed switch, the low drive speed
mode is active. Move downwards the drive high/low
speed switch, the high drive speed mode is active.
When the machine is in the operating position, the
machine can only be driven at the working speed.
Moving the drive high/low speed select switch will not
enable the high drive speed mode.
Indoor/outdoor mode：
For the setting method of the indoor/outdoor mode,
please see Setting method of indoor/outdoor mode.
DTC SYSTEM
Before operation：
1. Turn the key switch on the ground controller to
Platform.
2. Pull out the red emergency stop buttons on both the
ground and platform controllers to the ON position.
3. Ensure the battery is well connected.
To position platform：
Press the lift function enable button and hold the enable
switch on the joystick and push forward/backward the
joystick to raise/lower the platform.
To drive：
1. Press the the drive/steer enable button and hold the
enable switch on the joystick and push forward/
backward the joystick to drive the machine forward/
backward.
2. Speed up: slowly move the joystick off center.
3. Speed down：slowly move the joystick toward
center.
4. Stop：return the joystick to center or release the
enable switch.
When the boom is in operating position, the drive speed
of the machine will be restricted.
The battery condition will affect the machine
performance. When the platform display indiciates a
low battery level, the drive speed and lift speed of the
machine will go down.
To steer：
Press the drive/steer enable button and hold the enable
switch on the joystick and press the steer left/right
button to steer the machine left/right.
To select drive speed：
TIPPING HAZARD
The machine must be driven at low
speed when tilted.
When the machine tilt alarm sounds,
do not operation any function except
lowering, and not until the tilting
factor is eliminated can the machine
be used again.
1. With machine stowed, the machine can be driven in
high/low speed mode.
2. Press the drive high/low speed select switch to
select the desired drive speed. When the low drive
speed indicator light is on, the low drive speed
mode is active. When the low drive speed indicator
light is off, the high drive speed mode is active.
When the machine is in the operating position, the
machine can only be driven at the working speed.
Pressing the drive high/low speed select switch will not
enable the high drive speed mode.
Indoor/outdoor mode：
For the setting method of the indoor/outdoor mode,
please see Setting method of indoor/outdoor mode.
OPERATING WITH THE
PLATFORM CONTROLLER
ON THE GROUND
Before operating the machine with the platform control-
ler on the ground:
