2.0 Internal Connector Specification
User’s Manual Page 2-16
2.15 MiniPCI‐EConnector(MINICARD2)
Connector size 2 X 26 = 52 Pin
Connector type MINI PCI-E CON 9.2mmH
Connector location MINICARD2
Connector pin definition
Pin Signal Pin Signal
1 PCIE_WAKE# 2 3VSB
3 NC 4 GND
5 NC 6 +1.5V
7 MINICARD1
_
CLKREQ# 8 NC
9 GND 10 NC
11 PCIE_MCARD1
_
CLK_N 12 NC
13 PCIE_MCARD1
_
CLK_P 14 NC
15 GND 16 NC
17 NC 18 GND
19 NC 20 MINICARD1
_
DIS#
21 GND 22 PCIE_RST#
23 PCIE_MCARD1
_
RX_N 24 3VSB
25 PCIE_MCARD1
_
RX_P 26 GND
27 GND 28 +1.5V
29 GND 30 SMB_CLK
31 PCIE_MCARD1
_
TX_N 32 SMB_DATA
33 PCIE
_
MCARD1
_
TX
_
P 34 GND
35 GND 36 USB
_
5N
37 GND 38 USB
_
5P
39 3VSB 40 GND
41 3VSB 42 NC
43 GND 44 NC
45 NC 46 NC
47 NC 48 +1.5V
49 NC 50 GND
51 NC 52 3VSB
