5 Instrument hoses
5.1 Removal/Replacement of instrument hoses
Switch the unit OFF before removing the hoses!
Unscrew the cap nut (1) and then simply pull off the
instrument supply hoses.
After replacement, make sure to equip all holders with
the right instruments!
Possible equipment
in the instrument holder on the right:
• SIROSONIC L or
• SIROTOM or
• Satelec Mini L.E.D. curing light or
• SIROCAM 3 or SIROCAM C
in the second instrument holder from the right:
• Highspeed handpiece as 4th burr drive (only with up-
grade kit)
• SIROSONIC L or a
• Satelec Mini L.E.D. curing light,
Risk of scalding! After replacement of the SPRAYVIT
hose, no cooling water for the heating cartridge flows un-
til the hose is completely filled. Boiling hot water may es-
cape for a short while!
In order to prevent a hazard to the patient, proceed as
follows:
• Briefly press buttons several times until water and air
are available.
5.2 Checking the flow rate of the SPRAYVIT L
If the flow rate is less than 135 ml/min with the water but-
ton fully actuated, there is a risk of excessively hot water
being emitted.
You should therefore perform the following measure-
ment every 4 weeks to exclude a patient risk:
• Fill a measuring cup up to the 100 ml mark with the
water button fully actuated.
• Stop the filling time.
The filling time must be less than 45 seconds.
Risk of burning! The SPRAYVIT L must not be used on
the patient if the filling time is longer than 45 seconds. In
this case:
