7 Surfaces / O-rings Sirona Dental Systems GmbH
Care and cleaning instructions for the practice team C2
+
, M1
+
59 58 512 D 3370
28 D 3370.103.01.13.02
Dentist and assistant element
To facilitate cleaning or thermodisinfecting at 93°C
(197°F), the instrument racks on the dentist and assis-
tant elements can be removed.
ATTENTION
Use only cleaning agents which have been approved by
Sirona (see page 2, General information)!
Assistant element
The instrument rack can be removed by pulling on the
catch.
Dentist element
The silicone mat (11) can be sterilized.
To remove the instrument rack from the dentist element,
swivel the two levers (1) towards A.
To refit the rack, first place the front recesses on the two
bolts (2), press the rack on at the top and swivel the two
levers (1) towards B. Finally, make sure that the rack is
firmly seated.
If there is a ball stopper (12) fitted in an unused instru-
ment holder, it can be pushed out of the holder from the
rear for cleaning or thermodisinfection.
M1
+
tray,
The instrument tray can be removed to facilitate cleaning
or thermodisinfection at 93°C (197°F).
ATTENTION
Use only cleaning agents which have been approved by
Sirona (see page 2, General information)!
Care of the O-rings
• Use only approved lubricants (see page 2, General
information)
•Do not use vaseline or silicone grease. They cause
damage to the O-rings!
1
2 A
B
A
B
11
12
