2 Technical description Sirona Dental Systems GmbH
Operating Instructions PerioScan
61 95 825 D 3496
8 D 3496.201.03.05.02
2Technical description
Model designation PerioScan
Nominal voltage 120 VAC, 60 Hz
Nominal output of PerioScan 28 VA
Water requirements The rinsing/cooling water must be clean according to the
applicable regulations. It must not be contaminated.
Input pressure 1.5 – 5 bar
Dilution hardness 8° dH (1.43 mmol)
A water softener must be installed for water hardnesses
equal to or exceeding 12° dH (= 2.15 mmol).
Operating conditions Ambient temperature: 59 °F – 104 °F (15 °C – 40 °C)
Relative humidity: 30 % – 95 %
Air pressure: 700 hPa – 1060 hPa
Transport and storage conditions Temperature: -40 °F – 158 °F (-40 °C +70 °C)
Relative humidity: 10 % – 95 %
Air pressure: 500hPa – 1060hPa
After a severe change in temperature, allow sufficient
time for acclimatization.
Protection class PerioScan: Protection class I
Degree of protection against electrical shock Type B applied parts
Degree of protection against ingress of water and
foreign substances
IP 20 – PerioScan is protected against ingress of solid
foreign substances >
12.5 mm Ø. Not protected against
ingress of water.
IP X1 – The foot switch is protected against dripping
water.
Operating mode Continuous operation
Dimensions Width: 150 mm, depth: 305 mm, height: 220 mm
Weight (without ultrasonic handpiece) Approx. 4 kg, with rinsing media tanks full
Year of manufacture (on bottom side of unit)
Tests/approvals
This unit is intended exclusively for operating an ultra-
sonic handpiece approved by Sirona. Namely:
PerioSonic.
/158°F
/40°F
20XX
