SW Rest Secure System™ Specifications
Control Module
The Control Module is located under the bed.
Housing
Material ............................................................................................... ABS, UL94-V0 rated
Width............................................................................................................. 7.25” / 18.5 cm
Length ............................................................................................................. 3.25” / 8.5 cm
Thickness ........................................................................................................... 2.00” / 5 cm
Connectors
Power ............................................................................................... 2.1 mm Center Positive
Load Cell .............................................................................................................. 6 pin RJ11
Nurse Call ........................................................................................................1/4 Phono TS
CAN Network ...................................................................................................... 6 pin RJ11
Nurse Call
Open .......................................................................................................................... 0 Ohms
Alarm ..................................................................................................................... 0.3 Ohms
Output ...................................................................................................... 0.206 VRMS Max
External Power
AC Adapter .............................................................. 5.0 Volts, DC, UL Recognized supply
Current ......................................................................................... 800 mA, fused at 800 mA
Battery Power
Type ........................................................................................ 2 x AA, NiMH Rechargeable
Capacity ............................................................................................................... 1600 mAH
Recharge Time ....................................................... Normally 30 mins, from dead 120 mins
Operating Time ................................................................................. (No Alarms) 200 mins
Operating Current
Normal .............................................................................................................. 170-280 mA
Charging ....................................................................................................................320 mA
Alarming ...................................................................................................................275 mA
Weighing Function
Resolution ............................................................................................... 1-1.5 lbs. / .5-.7 kg
Sampling Frequency .................................................................................................... 10 Hz
Averaging ........................................................................................ 16 samples/ 1.6 seconds
WARNING: Any change to the specifications can result in malfunction or
damage to the SW Rest Secure System™.
