4.5.6.2 Connectivity
Example of connecting four reversing valves
and four piston detectors on devices with the
maximum equipment level (6x M12x1 circular
connectors) for operating a progressive feeder
system, distributed in four lubrication zones
A
B
C
CS.. = Piston detectors V.. = Reversing valves
2
4
5
3
1
6
7
34
1 2
Assignment of
round 7-pin plug
Assignment of
M12x1 4-pin round plug
are possible.
Legend for connection illustration with maximum equipment level
CS1 – CS4 Piston detectors 1 – 4 V1 – V4 Valves 1 – 4
MC Machine contact SL2 "Fault" indicator light can alternately
be operated in place of valve 4)
L+ + Supply voltage potential S1 Ignition switch
F1 Fuse
Assignment of
CAN bus plug
