Page #18 background imageLoading...
Page #18 background image
18
4.5.3 Setting the progressive distributor pulse count setting
Select channel 1 or 2 by pressing the button briefly.
When the system is in its normal status, hold the button for approximately 15 seconds until indicators 1 and 2 start
flashing rapidly.
Now the pulse count can be set. Indicator P will flash several times. The number of flashes corresponds to the current
pulse count setting, see the following table.
Number of
flashes
Number of
pulses
1
0
2
1
3
2
4
3
5
4
6
5
7
6
8
7
9
8
10
9
To change the pulse number setting, select the correct number of pulses from the table above and press the button as
many times as there are flashes indicated in the table. After reaching the biggest number, pressing the button will start
cycling numbers from the beginning.
NOTE
If the pulse number is set to zero (0), the pump will always operate for the set maximum pressurisation time.
4.5.4 Saving the set values and exiting the setting mode
To exit the setting mode and save the setting in the circuit board memory, hold the button for approximately 5 seconds,
after which all three indicators will light up.
4.5.5 Exiting the setting mode without saving settings
If you leave the device in setting mode for 3 minutes, the system will automatically exit from the mode without saving any
new values.

