SET-UP
Backrest
A22H0L6
1
Model(s): All Models except Expedition
Install spacers [
[[
[1]
]]
] (included in shrink kit) in
rear seat holes for backrest.
Install backrest in its proper position.
Secure rear arms of backrest using 2 M8 x
30 screws found in shrink pack.
Align front arms of backrest and secure with M8
x 20 screws included in the shrink pack.
Model(s): Expedition Series
mbl2006-002-002
Install backrest in its proper position and
screwtheknobtosecureit.
Drive Belt
Model(s): All except 4-TEC
WARNING
Engine should be running only when belt
guard is secured in place.
Remove belt guard.
Clean pulleys and disk brake with a suitable
cleaner such as pulley flange cleaner
(P/N 413 711 809).
Install drive belt in its proper rotation direction,
arrow pointing at front.
14 / 24 2006-1 Predelivery
