SET-UP
Install skis on snowmobile using bolts,
nuts, washers and rubber bushings supplied
in the predelivery kit.
Skis
A29F186
4
5
6
1
3
2
7
7
Model(s): TUV and SUV Only
N
NN
NO
OO
OT
TT
TE
EE
E:
::
: Ensure the ski leg bushing [
[[
[5]
]]
]is
still on the ski leg [
[[
[6]
]]
].
Insert the ski stopper [
[[
[1]
]]
] from the predelivery
kit with the higher side toward the front
[
[[
[3]
]]
] into the ski.
Install the ski [
[[
[7]
]]
] to ski leg [
[[
[6]
]]
].
Secure the ski to ski leg with:
– the existing M10 hexagonal bolt [
[[
[2]
]]
].
N
NN
NO
OO
OT
TT
TE
EE
E:
::
: Make sure that the hexagonal bolt head
is toward the outside of the vehicle.
– M10 elastic flanged nut [
[[
[4]
]]
] from the
predelivery kit.
Torque to 45 N•m(33 lbf•ft).
N
NN
NO
OO
OT
TT
TE
EE
E:
::
: Repeat the same procedure on
the opposite ski.
Put the vehicle back on the ground.
1
A29G1GA
Model(s): All except TUV and SUV
Install stop bounding [
[[
[1]
]]
] on skis with its
highest portion toward front.
On some models, a support plate should
be installed as per photo.
Install a washer on both side of ski leg.
3
4
6
1
4
2
5
3
Install skis on vehicle using the following
parts from the predelivery kit:
– [
[[
[1]
]]
] stop bounding (already installed)
– [
[[
[2]
]]
]sleeve
– [
[[
[3]
]]
] rubber bushings
– [
[[
[4]
]]
] conical spring washers (concave surface
inside) (SWT only)
– [
[[
[5]
]]
]bolts
– [
[[
[6]
]]
]nuts.
Predelivery 2006-1 7 / 24
