COMPACT DISPLAY OPTIONS
The EML 224 Compact display can be used in the following modes:
Log Repeater Compact CD401LR A simple repeater for speed
in 1 or 2 axis and trip. Limited
functionality.
Multi Repeater Compact CD401MR A comprehensive repeater for
many of the common NMEA
messages. Also functions for
user dened messages.
Multi Repeater Backwards CD401MB Same as CD401MR but
all speeds are in opposite
direction.
Single axis EML 124 Compact CD401E1 With Electronic unit (JB60CD),
sensor and cable.
Dual axis EML 224 Compact CD401E2 With Electronic unit (JB60CD),
sensor and cable.
EML 224 Compact Backwards CD401EB With Electronic unit (JB60CD),
sensor and cables.
Single axis DL1 Doppler CD401D1 With Electronic unit (JB60CD),
sensor and cables.
The software for all these options are stored in the system and the options can
be changed using a security code. This code can be obtained from
sales@skipper.no or by sending an order to SKIPPER together with the
systems serial number. (Obtained by opening the code screen in diagnostics).
On entering the supplied code number, the system options will be set.
However, please note that the cabling is different for the repeaters and the
main Compact speed log systems, so these are not compatible without
replacing the back plate.
CHANGING THE SYSTEM / ADDING OPTIONS
The Compact speed log is being developed as a low cost display alternative
to full graphics displays. Most extra features are available for the EML 224
Compact and these can be activated using the CODE page in the setup menu.
On this page, the systems unique ID is displayed. The new options can be
purchased from the SKIPPER retailer to add extra functions. You will receive
