an activation code and, if necessary, a software upgrade.
Entering the code on the CODE page will activate/deactivate the option.
NOTE: It is important to note that option codes are unique for each
individual unit and will not work on other units.
INTERFACING WITH YOUR DISPLAY
It is possible to retrieve conguration and diagnostic data from the Compact.
This can be performed by connecting to the electronic unit (JB60CD) ‘compact’
port, or directly through the NMEA port. In this way, error messages can be
retrieved when required.
The SKIPPER Service software are available if required.
The following messages exists:
• $PSKPVMPCGTER,x if x = 0 = Last error, other = whole table
• $PSKPVMPCDEMO,mm,lw.ll,tw,ta,lb,tb,ab,tmp,trip,total
where:
• mm = 0, auto.
• mm = 1, uses the following values: (see table)
• mm = 2, turn off.
Table showing mm = 1 values
lw longitudinal water value <xx.xx>
tw transversal water value <xx.xx>
ta aft transversal water value <xx.xx>
lb longitudinal bottom value <xx.xx>
tb transversal bottom value <xx.xx>
ab aft transversal bottom value <xx.xx>
tmp temperature <xx.xx>
trip trip distance value <xxxx>
total total distance value <xx.xx>
It may be necessary to remove other inputs on the same line (i.e remove power
from the sensor).
