80 User Manual
DOL 534 • DOL 539
5.4 Alarms for Climate
The temperature alarm for high temperature is only activate when the batch
state is Active house. The alarm is set as an excess temperature to
Temperature setpoint.
See also section 3.2.1.2.
FreeRange
The alarm limit in FreeRange houses increases when the pop-holes are open,
with an addition on the Fan temperature offset.
See also section 3.7.4.
Alarm for excessively low temperature in relation to the Temperature
setpoint.
Low temperature limit with
FreeRange
In FreeRange houses, the alarm limit is lowered with this setting when the
pop-holes are open.
Example: Heating installed but not active in
FreeRange
Temperature setpoint 19°C
Heating offset -2°C
Low temperature limit with FreeRange
-5°C
When not in FreeRange mode the
heating is set to 17°C
Alarm triggered at 12°C
Example: Heating active in FreeRange
Temperature setpoint 19°C
Heating offset -2°C
FreeRange-reduction -5°C
Low temperature limit with FreeRange
-5°C
When not in FreeRange mode the
heating is set to 17°C
In FreeRange heating is set to 12°C
Alarm is triggered at 7°C
When the pop-holes close, the alarm limits will return to the general
temperature alarm limits within 30 minutes
Summer temperature at 20° C
and 30° C outside
The function has a varying alarm limit which follows the changes that occur
in high outside temperatures. When the temperature increases, the alarm
limit also increases. It therefore delays the time at which the high
temperature alarm will be generated.
The DOL 53X controller generates the alarm only if the inside temperature
also exceeds the high temperature alarm.
Absolute high temperature
The alarm for absolute high temperature is generated by the actual
temperature, e.g. 32° C. DOL 53X will generate the absolutely high
temperature alarm when the inside temperature exceeds this setting.
Alarm for Absolute high temperature is
set like a temperature curve.
Temperature difference
between front and rear zones
(2 zones)
The alarm is active at Tunnel ventilation where ventilation is regulated
according to an average value of the front and rear temperatures. DOL 53X
generates an alarm when the temperature difference between the front and
rear zones exceeds the set number of degrees.
