29
Support Hotline: +49 (0) 2661 98088-112
Support E-Mail: support@sks-kinkel.de
Version No. 3.0
Document No. 97000104
SKS-Kinkel Elektronik GmbH
20002110 BS2012 Audio Hands-free
EN
8 Initial setup
8.1 Setting of call address (i. e. one call button for one indoor station)
Please set the call address needed at the device’s DIP switch according to the SKS call ad-
dress table (s. appendix). Each call address is assigned to one call button at the door station.
In case only the main call address is used, this doesn’t need to be programmed into
the indoor station, setting the DIP switch will be sucient.
8.2 Programming of call addresses
Programming call addresses is necessary only when
3 more than one bell buttons should be assigned to an indoor station (e. g. if there is more than one door station)
3 internal or group calls are to be set up
8.3 Programming of call addresses (i. e. two to four bell buttons for an indoor station)
If more than one bell button is assigned to one indoor station, all the relevant call addresses need to be programmed
into the indoor station.
To program call addresses follow these steps:
Step Description
1 If unsure whether call addresses have already been programmed into the indoor station or
which call addresses have been programmed we recommend to delete all call addresses
saved in the indoor station (s. next chapter “Deleting all call addresses”).
2 Set the DIP switch to the main call address (= 1st position in your storage space) which re-
sponds to calls made from the respective bell button at the door station.
7.4 Disassembly
Open the BS2012 Audio Hands-free Indoor station as described in chapter “Preparation” and remove it from the
supporting frame. Remove the cores of the cable from the terminals from the indoor station and also remove the
supporting frame by unscrewing it if necessary.
Programming key
DIP switch
