Appendix III: The Oponal Equatorial Wedge
If you plan to do a lot of astrophotography with SAM then you should
seriously consider purchasing the Equatorial Wedge (wedge). This
accessory makes the ne poinng control that is necessary for polar
alignment procedures much more easily accomplished than using a
standard lt/pan head or ball mount.
The Equatorial Wedge includes the following key parts:
Mounng Plate: The Mounng Plate includes a 1/4 inch threaded bolt for
aaching a camera or standard camera accessory, such as a ball mount.
Stopper: The Stopper acts as a safeguard against your camera payload
slipping out of the Saddle of the Equatorial Wedge should you let go of it
before ghtening the Mounng Plate Locking Knob.
Azimuth (Horizontal) Adjustment Knob: This knob enables ne poinng
of the wedge in the right and le direcons (azimuth direcons). It is
especially useful when making ne adjustments for the Easy and Advanced
Polar Alignment Procedures.
Altude (Vercal) Adjustment Knob: This knob enables ne poinng of
the wedge in the up and down (altude) direcons. It is especially useful
when making ne adjustments for the Easy and Advanced Polar Alignment
Procedures.
Altude Scale: This scale indicates the altude seng of the wedge. Note
that for polar alignment procedures, the altude of your wedge is equal to
the latude of your observing site if your wedge and tripod are set to level.
Bubble Level: A built-in level to assist you in seng your tripod and
wedge to level. Note that a perfectly level tripod is not a requirement
for using SAM in equatorial mode, but it does make the polar alignment
adjustments a bit easier.
Altude Lock Handle: Loosen this handle slightly before making latude
adjustments, then re-ghten when nished.
Mounng Plate
Azimuth
Adjustment
Knob
Stopper
Altude
Adjustment
Knob
Altude
Scale
Bubble
Level
Altude Lock
Handle
