SKY-WATCHER star adventurer mini - Sams Parts Diagram

SAM Parts Diagram
1: Power Buon
2: Power LED Indicator
3: WiFi LED Indicator
4: Polar View Finder
5: Knurled Tripod Connector
6: Tripod Connector Locking Knob
7: SNAP Port: DSLR Shuer Control
8: Micro USB Port
9: AA x 2 Baery Case
10: Saddle
11: Dovetail Locking Knob
12: Saddle Locking Knob
13: 1/4” to 3/8” Thread Adapter
14: 3/8” Threaded Side Socket
15: 3/8” Threaded Base Socket
1
2
3
4
6
7
8
9
10
11
12
13
14
15
5
5
