Skyjack SJ 4632 - Torque Specifications

Table 2.4 Torque Specifications
Directional valve mounting bolts
28-32 in-lb 2.2 – 3.6 Nm
Wheel mounting bolts
90 ft-lb 122.02 Nm
Cartridge
Size
Torque
08 38 58 10 12 16
Ft-lb (max)
20 20 20 25 35 50
In-lb (max)
240 240 240 300 420 600
Nm (max)
27.12 27.12 27.12 33.90 47.46 67.80
Coils
Size
Torque
All coils
Ft-lb (max)
4 to 5
In-lb (max)
48 to 60
Nm (max)
5.42 to 6.78
SAE Plugs
Size
Torque
2 4 5 6 8 10 12 16
Ft-lb (max)
3 10 15 15 25 25 30 35
In-lb (max)
36 120 180 180 300 300 360 420
Nm (max)
4.07 13.56 20.34 20.34 33.90 33.90 40.68 47.46
Newton-meter = Nm Foot-pound = ft-lb Inch-pound = in-lb
Additional Torque Specifications may be found in Section 3.
