Skyjack SJ 4632 - Platform Control Console with Rotary Switch - Powered Extension Platform Modification Diagram

SKYJACK, Page 16 SJIII Conventional Series
143911
Service and Maintenance Section 3 - System Component Identification and Schematics
3.8b Platform Control Console with Rotary Switch - Powered Extension Platform Modification Diagram
02
X1
X2
14
15
12
11
13
16
102
(15) BLUE
(02) WHITE
1 9
(7A) GREEN
(49) GREEN WHITE
(8C) BLUE WHITE
(07) RED
(14) BLACK
(13) ORANGE
8
5
4
3
6
7
BACK VIEW
(NOT USED)
RED BLACK (18)
MALE
WHITE BLACK (16)
ORANGE BLACK (59)
GREEN BLACK (21B) (OPT)
BLACK WHITE (23)
RED WHITE (60/7A)
BLUE BLACK (24)
09
02
26 27
21B
21B
08
08
2.WHITE (09)
3.GREEN (26)
4.(N/U)
1.BLACK (27)
3.GREEN (26)
2.WHITE (02)
1.BLACK (27)
D26 D27
SOLENOID VALVES
TO POWER EXTENSION PLATFORM
CONTROL CONSOLE
TO POWER EXTENSION PLATFORM
09
LED-1
HYDRAULIC PROPORTIONAL
MIDDLE SECTION
S3 - LIFT/DRIVE SELECTOR
BOTTOM SECTION
S3 - LIFT/DRIVE SELECTOR
TOP SECTION
S3 - LIFT/DRIVE SELECTOR
S4 - EMERGENCY STOP
S8 - HORN
M146620AB
Serial Breakdown
Reference Chart
Model Serial Number
SJ3 3220 60002137 & below
SJ3 3226 27006058 & below
SJ3 46XX 70006693 & below
AC
