Skyjack SJ 4632 - Platform Control Console with Toggle Switch - Powered Extension Platform Modification Diagram

SKYJACK, Page 15SJIII Conventional Series
143911
Section 3 - System Component Identification and Schematics Service and Maintenance
3.8a Platform Control Console with Toggle Switch - Powered Extension Platform Modification Diagram
02
S8 - HORN
S4 - EMERGENCY STOP
S3 - LIFT/OFF/DRIVE
S27 - TORQUE
TO PWR DECK
CONTROL BOX
TO PWR DECK
SOLENOID VALVES
D27D26
PIN 1 - 27 BLACK
PIN 2 - 02 WHITE
PIN 3 - 26 GREEN
PIN 4 - N / U
PIN 5 - N / U
PIN 1 - 27 BLACK
PIN 4 - N / U
PIN 5 - N / U
PIN 3 - 26 GREEN
PIN 2 - 09 WHITE
08
21B
21B
2726
02
09
BLUE BLACK (24)
RED WHITE (60/7A)
BLACK WHITE (23)
GREEN BLACK (21B) (OPT)
ORANGE BLACK (59)
WHITE BLACK (16)
MALE
RED BLACK (18)
(NOT USED)
BACK VIEW
7
6
3
4
5
8
(13) ORANGE
(14) BLACK
(07) RED
(8C) BLUE WHITE
(49) GREEN WHITE
(7A) GREEN
91
(02) WHITE
(15) BLUE
2
10
16
13
11
12
15
14
X2
X1
LED-1
09
08
M156955AA
Serial Breakdown
Reference Chart
Model Serial Number
SJ3 3220 60002138 & above
SJ3 3226 27006059 & above
SJ3 46XX 70006694 & above
AC
