SECTION 6, Page 7SJ-800 Series E Battery Powered
119153
Parts list continued from the previous page.
17 107617 2 RAILING, Lower front LH/lower rear RH
18 104183 2 PAD, Entry insulation 27” lg. (Half gate)
20 107621 1 RAILING, Upper rear RH, B
111840 1 RAILING, Upper rear RH, A & C
21 111845 AR RAILING, Hinged upper end, C
22 111842 AR RAILING, Hinged lower end, C
23 107621 1 RAILING, Upper front RH, A & B
111808 1 RAILING, Upper front RH, C
24 132814 1 ASSEMBLY, Control box mount
  132816 1 • WELDMENT,Controlboxmount
  103865 2 • BOLT,Hexhead(5/16-18x2”lg.)
  103984 2 • NUT,Lock(5/16-18)
  103996 2 • WASHER,Flat(5/16”)
  124547 1 • PIN,Quickreleaseassy.smallloop
  134355 1 • SCREW,Machineflathead(1/4”-20x3/4”)
  115649 1 • NUT,Hexnylonlock(1/4”-20Grade5)
25 108791 1 CLIP, Cable (stick-on)
26 107621 1 RAILING, Upper front LH, A & B
111840 1 RAILING, Upper front LH, C
27 100509 AR PIN, Locking 3/8”
28 105807 AR CABLE, Lanyard 6” lg.
29 107614 8 PLATE, Railing retainer
30 (Ref.) - RING KIT, Safety
(For components, Refer to Figure 6.7-8)
31 120143 1 Extension, Gate (CE)
32 119943 1 PLATE, Gate clamp (CE)
33 119945 4 RIVET, Pop Wide Head (CE)
34 121017 AR RAILING, Bottom Left, D
35 121016 AR RAILING, Bottom Right, D
36 121015 AR RAILING, Top, D
37 117279 AR GATE, Full (Left swinging) D
125010 AR GATE, Full (Right swinging) D
Figure 6.1-1. Main Platform And Railings (Continued)
Index
No.
Skyjack
Part No.
Description Qty.
