Skyjack SJ12 Service Manual

30
213558ADA
SJ12, SJ16
Section 2 – Maintenance Tables and Diagrams Specifications and Features - CE, AS
2.3 Specifications and Features - CE, ASTable
Model SJ12 SJ16
Weight * 863 kg 980 kg
Overall Width 0.78 m 0.78 m
Overall Length 1.40 m 1.40 m
Platform Size (Inside) 0.68 m x 0.85 m 0.68 m x 0.85 m
Platform Traversing 0.41 m 0.41 m
Height
Working Height 5.66 m 6.75 m
Platform Elevated Height 3.66 m 4.75 m
Stowed Height 1.78 m 1.78 m
Drive Height Full Full
Lowered Platform Height 0.45 m 0.45 m
Standard Operating Times
Lift Time (Rated Load) 13 s - 16 s 16 s - 25 s
Lower Time (Rated Load) 13 s - 17 s 17 s - 19 s
Chassis
Normal Drive Speed 3.1 km/h - 4.0 km/h 3.1 km/h - 4.0 km/h
Elevated Drive Speed 0.6 km/h - 0.8 km/h 0.6 km/h - 0.8 km/h
Gradeability (Ramp Angle [Reverse/Forward])** 30% / 25% 30% / 25%
Tires (Solid Rubber) 309 mm x 100 mm 309 mm x 100 mm
Hydraulic Oil
Type ATF Dexron III ATF Dexron III
Tank Capacity 4.9 L 4.9 L
* Weights are approximate; refer to serial nameplate for specific weight.
**Refer to
Section 6.4 Move the MEWP for Transport in the Operation manual for more details.
1838AB

Skyjack SJ12 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Machine Width	32 in (0.81 m)
Stowed Height	6.5 ft
Overall Width	32 in (0.81 m)
Stowed Height (Rails Folded)	6.5 ft
Drive Speed (Elevated)	0.5 mph (0.8 km/h)
Power Source	Electric
