Skyjack SJ12 Service Manual

A B C D E F G H
V
Z
Y
X
W
62
SJ12, SJ16
213558ADA
3.22 Limit Switches
M213192AD
WIRE
WIRE NUMBER
BROWN
B+
BLUE
18X
BLACK
21
BLACK/WHITE
71
YELLOW/GREEN NOT USED
CAVITY
1
2
3
4
NOT USED
LS1 - MAST LIMIT SWITCH
LS4 - DRIVE CUTOUT LS3 - SERVICE
LIMIT SWITCHES (LS4 AND LS3)
WIRE
WIRENUMBER
CAVITY
BLACK 19A C5
BLACK 02 HOURMETER +
BLACK/WHITE 19B C10
BROWN
7A
C3
BLUE 7B
C8
YELLOW/GREEN NOT USED NOT USED
WIRE
WIRENUMBER
CAVITY
BLACK N/C
B1
BLACK/WHITE N/C C7
BROWN 12A B9
BLUE 7B
B10
YELLOW/GREEN NOT USED NOT USED

Skyjack SJ12 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Machine Width	32 in (0.81 m)
Stowed Height	6.5 ft
Overall Width	32 in (0.81 m)
Stowed Height (Rails Folded)	6.5 ft
Drive Speed (Elevated)	0.5 mph (0.8 km/h)
Power Source	Electric
