Skyjack SJ12 Service Manual

37
SJ12, SJ16
213558ADA
Torque Specifications for Fasteners (Metric) Section 2 – Maintenance Tables and Diagrams
2.10 Torque Specifications for Fasteners (Metric)Table
Size Torque Type
SAE2 SAE 5
Dry Lubed Dry Lubed
M5 x 0.80
(in-lb) (54) (41) (78) (59)
Nm 6.1 4.6 8.8 6.7
M6 x 1.00
(in-lb) (92) (69) (133) (99)
Nm 10.4 7.8 15 11.2
M7 x 1.00
(in-lb) (156) (116) (222) (167)
Nm 17.6 13.1 25.1 18.9
M8 x 1.25
(in-lb) (225) (169) (333) (242)
Nm 25.4 19.1 37.6 27.3
M10 x 1.50
ft-lb 37 28 53 40
Nm 50 38 72 54
M12 x 1.75
ft-lb 65 49 93 69
Nm 88 66 126 94
M14 x 2.00
ft-lb 104 78 148 111
Nm 141 106 201 150
M16 x 2.00
ft-lb 161 121 230 172
Nm 218 164 312 233
M18 x 2.50
ft-lb 222 167 318 238
Nm 301 226 431 323
M20 x 2.50
ft-lb 314 235 449 337
Nm 426 319 609 457
M22 x 2.50
ft-lb 428 321 613 460
Nm 580 435 831 624
M24 x 3.00
ft-lb 543 407 776 582
Nm 736 552 1052 789
M27 x 3.00
ft-lb 796 597 1139 854
Nm 1079 809 1544 1158
M30 x 3.50
ft-lb 1079 809 1543 1158
Nm 1463 1097 2092 1570
M33 x 3.50
ft-lb 1468 1101 2101 1576
Nm 1990 1493 2849 2137
M36 x 4.00
ft-lb 1886 1415 2699 2024
Nm 2557 1918 3659 2744
Inch-Pound Force = in-lb Foot-Pound Force = ft-lb Newton-Meter = Nm
NOTE: Lubed includes lubricants such as lubrizing, oil, grease, or uncured Loctite.
1613

Skyjack SJ12 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Machine Width	32 in (0.81 m)
Stowed Height	6.5 ft
Overall Width	32 in (0.81 m)
Stowed Height (Rails Folded)	6.5 ft
Drive Speed (Elevated)	0.5 mph (0.8 km/h)
Power Source	Electric
