45
Electrical Component Parts LIst Section 3 – System Component Identification and Schematics
3.5 Electrical Component Parts LIst
Index
No.
Skyjack
Part No.
Description
- - Parts list continued from previous page.
C1 165865 CONTACTOR
164671 • Kit,Diode
D12B 129258 DIODE (8 Amp)
DA 102921 DIODE (6 Amp)
DB 102921 DIODE (6 Amp)
DCM1 156877 MOTOR
F1 310517 FUSE (300 Amp)
LED-1 147061 POWER INDICATOR LIGHT (Platform control console)
LED-2 147061 POWER INDICATOR LIGHT (Base control centre)
LS1 199406 LIMIT SWITCH (High speed)
LS2 199401 LIMIT SWITCH (Pothole protection)
LS3 229309 LIMIT SWITCH (Service position)
LS4 229308 LIMIT SWITCH (Drive cutout)
RST1 119629 RESISTOR (2.7k ohm) (Platform control console)
RST2 158707 RESISTOR (845 ohm, 1 watt) (Base control centre)
RST3 156515 RESISTOR (220 ohm, 3/4 watt) (Base control centre)
RST4 151645 RESISTOR (4.7k ohm, 1 watt) (Base control centre)
RST5 156527 RESISTOR (2k ohm, 2 watt) (Base control centre)
RST6 151643 RESISTOR (250 ohm, 1 watt) (Base control centre)
RST7 156564 RESISTOR (1.5 ohm, 1 watt) (Base control centre)
RST8 151647 RESISTOR (68 ohm, 1 watt) (Base control centre)
S1 119725 SWITCH, Main power disconnect
S2 147054 N.O. CONTACT, Lift/Drive (Base control centre)
S3 147053 N.C. CONTACT, Lift/Drive (Platform control console)
147054 N.O. CONTACT, Lift/Drive (Platform control console)
S4 147053 N.C. CONTACT, Emergency stop (Platform control console)
S5 115573 SWITCH, Diagnostic
S7 151201 CONTROLLER ASSEMBLY
S8 147054 N.O. CONTACT, Horn (Platform control console)
S10 147053 N.C. CONTACT, Off/Platform/Base (Base control centre)
147054 N.O. CONTACT, Off/Platform/Base (Base control centre)
S28 147053 N.C. CONTACT, Emergency stop (Base control centre)
TT1 195940 HOUR METER
TS1 157375 SWITCH, Tilt
To Next Page
