Section 7 – Technical Drawings and Specications Floor Loading Pressure
7.8 Floor Loading Pressure
Models
Gross MEWP
Weight
Total MEWP Load
Wheel LCP OUP
kg lb kg lb kPa psi kPa psf
SJ30 AJE
5,815 12,820 3,255 7,180 1,503 218 21.6 451
SJ30 ARJE
• Gross MEWP Weight = Weight + platform capacity
• Gross MEWP Weight = Weight + platform capacity
• LCP – Locally Concentrated Pressure – is a measure of how hard the MEWP tire tread presses on the area in direct
contact with the oor. The oor covering (tile, carpet, etc.) must be able to withstand more than the indicated values above.
• OUP – Overall Uniform Pressure – is a measure of the average load the MEWP imparts on the whole surface projected
directly underneath it. The structure of the operating surface (beams, etc.) must be able to withstand more than the
indicated values above.
e.
NOTE
The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally
determined by the engineer or architect for that particular structure.
