Skyjack SJ30 AJE User Manual

27
SJ30 AJE SJ30 ARJE 213213AAA
Features and Devices Section 3 – Familiarization
≤ 6.4 cm
≤ 2.5 in
≥ 90°
≤ 90°
Figure 09 Lowered travel position
> 6.4 cm
> 2.5 in
< 90°
> 90°
Figure 10 Elevated travel position (any of the boom
positions shown)
FAMILIARIZATION
3.4 Features and Devices
3.4-1 Lowered travel position and elevated
travel position
Available MEWP functions depend upon a combination
of machine conguration (lowered travel position/
elevated travel position), chassis tilt, and platform load.
The MEWP is in the lowered travel position if it is in ALL
of the positions shown in Figure 09.
The MEWP is in the elevated travel position if it is in
ANY of the positions shown in Figure 10.
