SJ30 AJE & SJ30 ARJE Labels Section 8 – Labels
Description Label Pictorial
5
Boom speed adjuster dial/Platform/Boom/Jib controls
Adjust dial to vary speed of y boom extension/retraction, jib
raising/lowering and platform rotation movements.
Select platform rotation switch to rotate platform to the left or
right.
Select boom extend/retract switch to extend or retract y boom.
Select jib rotation switch to rotate jib to the left or right.
Select platform leveling override switch to tilt platform up or
down.
Select riser raise/lower switch to raise or lower riser.
Select jib up/down switch to move jib up or down.
6
Boom/Turret controller
Push and hold controller to rotate turret to the left or right.
Push and hold the controller to raise or lower main boom.
Platform control console (continued)
