Section 2 – Maintenance Tables and Diagrams Specifications and Features - CE, AS & KC
SJ30ARJE
CE
SJ30ARJE
AS
SJ30ARJE
KC
Performance
and Speeds
Gradeability - Maximum 35% 35% 35%
Drive Speed - Stowed 4.8 km/h 4.8 km/h 4.8 km/h
Drive Speed - Elevated 0.6 km/h 0.6 km/h 0.6 km/h
Turret Rotation Time 70-90 s 70-90 s 70-90 s
Platform Rotation Time 7-10 s 7-10 s 7-10 s
Main Boom Up Time 20-24 s 20-24 s 20-24 s
Main Boom Down Time 18-20 s 18-20 s 18-20 s
Fly Boom Extend Time 17-19 s 17-19 s 17-19 s
Fly Boom Retract Time 12-16 s 12-16 s 12-16 s
Riser Up Time 14-18 s 14-18 s 14-18 s
Riser Down Time 22-26 s 22-26 s 22-26 s
Jib Swing Time 14-16 s 14-16 s 14-16 s
Jib Up Time 18-20 s 18-20 s 18-20 s
Jib Down Time 12-16 s 12-16 s 12-16 s
Steer Left/Right Time 2-4 s 2-4 s 2-4 s
Tire Data
Tire Size 5.59 x 1.78 m 5.59 x 1.78 m 5.59 x 1.78 m
Diameter, Outside 5.59 m 5.59 m 5.59 m
Width 1.78 m 1.78 m 1.78 m
Electrical
Data
Battery Voltage 48V DC 48V DC 48V DC
Battery Type Lead/Acid Lead/Acid Lead/Acid
Weights & Pressure
Data
Overall Weight - No Options 5750 kg 5590 kg 5750 kg
Wheel Load - Transport with No Load 1590 kg 1590 kg 1590 kg
Wheel Load - Maximum with Load 3255 kg 3255 kg 3255 kg
LCP - Transport with No Load 954 kPa 954 kPa 954 kPa
LCP - Maximum with Load 1505 kPa 1505 kPa 1505 kPa
OUP - No Load 21.4 kPa 20.8 kPa 21.4 kPa
OUP - With Load 22.2 kPa 21.6 kPa 22.2 kPa
2.11 Specifications and Features - CE, AS & KCTable
