Skyjack SJ30AJE - 3.4 Hydraulic Parts List

49
SJ30AJE, SJ30ARJE 196274AF
Hydraulic Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Qty. Description
C1 192078 1 CYLINDER, Steer
C2 192073 1 CYLINDER, Main boom lift
C3 207328 1 CYLINDER, Riser (serial number 90 000 013 & above)
C3 192072 1 CYLINDER, Riser (serial numbers 90 000 001 to 90 001 012)
C4 192074 1 CYLINDER, Fly boom extension
C5 207339 1 CYLINDER, Jib
C6 192077 1 CYLINDER, Slave (platform levelling)
C7 192076 1 CYLINDER, Master
CB1 209153 1 VALVE, Counterbalance (main boom)
CB2 209153 1 VALVE, Counterbalance (main boom)
CB3 141453 1 VALVE, Counterbalance (fly boom extend)
CB4 141453 1 VALVE, Counterbalance (fly boom retract)
CB5 209153 1 VALVE, Counterbalance (platform level)
CB6 209153 1 VALVE, Counterbalance (platform level)
CB7 149372 1 VALVE, Counterbalance (jib elevation)
CB8 149372 1 VALVE, Counterbalance (jib elevation)
CB9 209153 1 VALVE, Counterbalance (platform rotary actuator)
CB10 209153 1 VALVE, Counterbalance (platform rotary actuator)
CB11 141453 1 VALVE, Counterbalance (jib rotary actuator)
CB12 141453 1 VALVE, Counterbalance (jib rotary actuator)
CV1 199471 1 VALVE, Check (main manifold)
CV2 208883 1 VALVE, Check (main manifold)
CV3 199471 1 VALVE, Check (riser cylinder)
CV4 197770 1 VALVE, Check (main manifold)
CV5 199471 1 VALVE, Check (main manifold)
F1 108628 1 FILTER, Hydraulic oil
M1 207350 1 MOTOR, Turret rotation swing drive
MB1 192161 1 MANIFOLD, Main
MB2 192162 1 MANIFOLD, Jib (SJ30AJE)
MB2 192055 1 MANIFOLD, Jib (SJ30ARJE)
OR1 208880 1 ORIFICE (0.040") (main manifold)
OR2 209023 1 ORIFICE (0.025") (jib manifold)
OR3 192122 1 ORIFICE (0.020") (jib manifold)
OR4 192122 1 ORIFICE (0.020”) (jib manifold)
OR5 208880 1 ORIFICE (0.040”) (riser cylinder)
P1 209056 1 PUMP, Main
P2 192176 1 PUMP, Auxiliary
