50
SJ30AJE, SJ30ARJE196274AF
Section 3 – System Component Identification and Schematics Hydraulic Parts List
Index
No.
Skyjack
Part No.
Qty. Description
RA1 192206 1 ACTUATOR, Turret rotator
RA2 192208 1 ACTUATOR, Platform rotator
RA3 192207 1 ACTUATOR, Jib rotator
RV1 208876 1 VALVE, Relief (main manifold)
RV2 208877 1 VALVE, Relief (main manifold)
RV3 208878 1 VALVE, Relief (main manifold)
RV4 208879 1 VALVE, Relief (main manifold)
RV5 209058 1 VALVE, Relief (main pump)
RV6 209058 1 VALVE, Relief (auxiliary pump)
RV7 209110 1 VALVE, Relief (riser cylinder)
V1 208872 1 VALVE, Control (steer cylinder)
V2 166036 1 VALVE, Control (master cylinder)
V3 166041 1 VALVE, Control (main boom lift)
V4 208875 1 VALVE, Control (turret rotary actuator)
V5 208874 1 VALVE, Control (riser cylinder)
V6 166050 1 VALVE, Control (flow enable)
V7 166036 1 VALVE, Control (fly boom)
V8 166036 1 VALVE, Control (jib cylinder)
V9 166036 1 VALVE, Control (platform rotary actuator)
V10 166036 1 VALVE, Control (jib rotary actuator)
V11 209109 1 VALVE, Counterbalance (riser cylinder)
