Models SJ6832 RTE
Weight (Without Outriggers)* 3780 kg
Weight (With Outriggers)* 3845 kg
Overall Width 1.765 m
Overall Length (Platform Retracted) 2.720 m
Overall Length (Platform Extended) 4.110 m
Platform Length, Inside (Platform Retracted) 2.440 m
Platform Length, Inside (Platform Extended) 3.900 m
Height
Working Height 11.7 m
Platform Elevated Height 9.7 m
Stowed Height (Railings Up) 2.510 m
Stowed Height (Railings Down) 1.750 m
Drive Height (Maximum) FULL
Standard Operating Times
Lift Time (No Load) 32 - 36 sec
Lower Time (No Load) 44 - 48 sec
Lift Time (Rated Load) 37 - 41 sec
Lower Time (Rated Load) 34 - 38 sec
Chassis
Normal Drive Speed (Stowed) 5.78 - 6.10 km/h
Elevated Drive Speed 0.52 - 0.61 km/h
Gradeability (Torque Equivalent To) 45 %
Tires (Foam Filled) 30.5 cm x 66 cm
Hydraulic Oil
Type ATF Dexron III
Tank Capacity 71 L
1859AA
* Weights are approximate; refer to serial nameplate for specific weight.
