Rough Terrain Scissors
December 2007 Page 63
Floor Loading Pressure
Width
LengthLength
Length
Width
Diameter
WARNING
Intermixing tires of different types or using tires of types other than those originally supplied with
this equipment can adversely affect stability. Therefore, replace tires only with the exact Skyjack-
approved type. Failure to operate with matched approved tires in good condition may result in
death or serious injury.
Locally Concentrated Pressure (LCP): Overall Uniform Pressure (OUP):
Foot Print Area = Tread Contact Area
Base Area = Length x Width
LCP =
Maximum Wheel Load
Foot Print Area
OUP =
Weight of Aerial Platform + Capacity
Base Area
Foot Print Area
