Page 47

Item Part No. Description Qty.

20. AUR WALL CONTROL

1 B9-310-07 FLANGE, recess mount, single or dual .................................................................... A/R

B9-310-08 FLANGE, recess mount, triple ................................................................................. A/R

2 B9-210-40 SCREW, ﬂange mounting ............................................................................................ 8

 3 B9-210-41 SCREW,covermounting ............................................................................................. 4

4 B9-210-09 COVER, electrical access ............................................................................................ 2

5 B9-610-53 HOUSING, wall control, single or dual .................................................................... A/R

B9-610-54 HOUSING, wall control, triple .................................................................................. A/R

6 B9-210-43 SCREW w/washer ....................................................................................................... 4

7 B9-710-06 PANEL, wall control front, AUR7 or AUR5 ............................................................... A/R

B9-710-07 PANEL, wall control front, AUR75 or AUR55 ........................................................... A/R

B9-710-08 PANEL, wall control front, AUR755 or AUR555 ....................................................... A/R

8 B9-610-66 FUSE, 2A timelag .................................................................................................... A/R

9 B9-610-65 FUSE HOLDER ....................................................................................................... A/R

10 B9-610-59 TOUCH PAD, dimmer control assembly ................................................................... A/R

11 B9-610-58 SWITCH, color temperature indicator .......................................................................... 1

12 B4-242-73 SWITCH, main power, DPST, yellow ........................................................................... 1

13 B9-710-09 CIRCUIT BOARD, single.......................................................................................... A/R

B9-710-10 CIRCUIT BOARD, dual ............................................................................................ A/R

B9-710-11 CIRCUIT BOARD, triple ........................................................................................... A/R

14 B9-610-70 SCREW .................................................................................................................... A/R

15 B4-342-62 WASHER, star, M4 ................................................................................................... A/R

16 B9-610-71 SCREW ........................................................................................................................ 4

17 B9-610-60 SCREW .................................................................................................................... A/R

18 B9-510-18 NUT, lock, M4 ........................................................................................................... A/R

19 B9-610-61 PLATE, power supply unit, single or dual ................................................................. A/R

B9-610-62 PLATE, power supply unit, triple .............................................................................. A/R

20 B9-710-14 NUT .............................................................................................................................. 2

21 B9-719-13 USB CONNECTOR ...................................................................................................... 1

22 B9-610-82 CIRCUIT BOARD, 20,000 hour indicator ..................................................................... 1

23 B9-710-12 POWER SUPPLY UNIT ........................................................................................... A/R

24 B9-710-15 MOUNT, noise ﬁlter ...................................................................................................... 1

25 B9-710-16 NOISE FILTER ............................................................................................................. 1

26 B9-710-17 SCREW .................................................................................................................... A/R

27 B9-710-18 CORE (large) ........................................................................................................... A/R

Skytron AURORA LED Series User Manual
