SL Analytics TitroLine 5000 - Dosing Unit and Accessories

89
2.5 Dosing unit and Accessories
Fig 8
1) TZ 2003 - drying tube
2) TZ 3282 - dosing hose without dosing tip and holding bracket
3) TZ 3802 - threaded cap with borehole GL 45, incl. adapter with 2 openings for drying tube and
suction hose
4) TZ 1748 - stand rod
5) Z 305 - titration clamp
6) TZ 3620 - dosing hose with dosing tip and holding bracket: bracket = TZ 3875
7) TZ 3803 - 1 litre reagent bottle, brown
8) TZ 3656 - titration tip unit, blue
9) TZ 3801 - valve cover lid and TZ 3000 - 3/2-way valve
10) TZ 3130 - 20 ml dosing unit or TZ 3160 50 ml dosing unit
11) TZ 3283 - connection hose
12) TZ 3281 - suction hose
1
2
3
4
5
6
7
8
9
10
11
12
