Page 22 (Model K)
5. ENGMODE
The SLE4000 ventilator is calibrated via two calibration programs, one for the
ventilator and one for the Touch screen. The calibration programs are accessed
via the Controller Services panel in the user interface.
Note: The calibration program is common to SLE4000 and SLE5000
ventilators.
5.1 Accessing the Calibration Programs
Step 1 Press the Options and Service Data
Button.
Step 2 Press the Next button.
Step 3 Press the Version button.
To Next Page
