SLE SLE4000 - 34 Equipotential Stud Modification

Page 268 (Model K)
34. Equipotential stud modification
Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
1 T1193/EP Top cover with EP stud RF
5 T1193/EP/01 (1) Stud, EP 1
Attaching Parts
10 H6091 Nut 2
15 H6093 Washer 2
20 H6094 Washer, shakeproof 2
25 H6093 Washer, M6 1

30 W0325/EP Cable, EP stud earthing 1

35 T1193/02 Top cover, with EP stud hole.

5
1
25
30
10
20
15
15
20
10
35
